(1) P3.91 LED display module size: 250*250mm / 500*250 mm (2) P3.91 LED cabinet size: 500*500mm & 500*1000mm & 1000*1000mm (3) High refresh rate, high contrast, and high grayscale for stunning visuals. (4) Ultra-thin and ultra-light screen design, easy installation and easy moving. (5) Wide viewing angle for better viewing experiences. (6) Low power consumption significantly reduces costs, and environment-friendly. (7) Ultra-thin, ultra-light design for easy portability, installation, dismantling, and maintenance. (8) Special heat dissipation structure for efficient cooling and quiet fanless operation. (9) 3 Years warranty and 5% spare parts.
Compare seller offers
Prices and availability provided by sellers.
Specifications
- Kind
- Display Module, Led Panel
- Feature
- 9mm Pixel Pitch
- Form
- Lh039isccyc En
- PL3.9-PRO-V10 spec sheet
- Mfr #
- PL3.9 Pro V10
- Weight
- 6kg(500 x 500mm cabinet)/ 11kg (500 x 1000mm cabinet)
- Warning
- Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
- Led type
- Common Cathode Black SMD 3in1 1921
- Warranty
- 3 years standard product warranty
- Grayscale
- 14 bit / 18bit
- Ip rating
- IP54 for Indoor, IP65 for Outdoor
- Brightness
- Indoor 600nits, Outdoor 4500nits;
- Dimensions
- 500 x 500 x 80 mm /500 x 1000 x 80 mm(WxHxD)
- Gray scale
- 14 Bit
- Grey level
- 14 bits
- Our part #
- PL3.9-PRO-V10
- Panel size
- (WxHxD) 19.7″ x 19.7″ x 3.4″/500 x 500 x 87mm
- Certificate
- CE,ETL,FCC,ROHS
- Module size
- 250*250mm
- Pixel pitch
- 3.9mm
- Driving type
- 1/8
- Panel weight
- 8.4kg
- Refresh rate
- 3840-7,680Hz
- Viewing angle
- (H/V) 140° / 140°
- Certifications
- CE, UL, FCC class A, RoHS, WEE, REACH
- Contrast ratio
- 7500:1
- Panel material
- Die Casting Aluminum
- Serviceability
- Frontal & Rear Service Indoor. Rear Service For Outdoor.
- Pixel per panel
- 128x128
- Brightness (nit)
- 1
- Max rigging qty.
- 20
- Storage humidity
- 10%～90% RH
- Color temperature
- 6500 K
- Hor. viewing angle
- 140° +/-5° (@50% brightness)
- Module maintenance
- Front or Rear
- Storage temperature
- ‑40～+60 ℃
- Vert. viewing angle
- 140° +/-5° (@50% brightness)
- Viewing angle (h/v)
- 140/140°
- Ac operating voltage
- 100～240 V
- Operational humidity
- 10-80%
- Operating temperature
- ‑20～+50 ℃
- Ip rating (front/rear)
- IP65/IP54
- Pixel matrix per panel
- 128 x 128 pixel
- Module dimensions (wxh)
- 250x250 mm
- Operation power voltage
- 100-240V / 50-60Hz
- Operational temperature
- -10°C to +40°C / 14°F to 104°F
- Panel installation type
- Hanging/Stacking
- Panel dimensions (wxhxd)
- 500x500x88 mm
- Psu & others maintenance
- Rear
- (2) p3.91 led cabinet size
- 500*500mm & 500*1000mm & 1000*1000mm
- Power consumption (max./avg.)
- 680/230 W/m²
